Product Overview

The Muonix RF 433MHz Receiver and Transmitter Module is a compact wireless communication module designed for short-range RF data transmission. Operating at 433.92MHz, it includes a transmitter and receiver module for reliable wireless communication between microcontrollers and electronic devices. It is ideal for Arduino, Raspberry Pi, IoT, home automation, and remote control applications.

Key Features

Operates at 433.92MHz RF frequency.

• Includes both transmitter and receiver modules.

• Supports ASK/OOK modulation.

• Receiver offers high sensitivity for reliable communication.

• Wireless transmission range up to 200 meters (depending on conditions).

• Low power consumption for battery-powered projects.

• Compatible with Arduino, ESP32, ESP8266, Raspberry Pi, and other micro-controllers.

• Supports external antennas for improved signal range.

Technical Specifications

• Product Type: 433MHz RF Receiver & Transmitter Module Kit

• Operating Frequency: 433.92MHz

• Modulation: ASK/OOK

• Receiver Voltage: 5V DC

• Transmitter Voltage: 3.3V - 5V DC

• Receiver Sensitivity: -108 dBm

• Maximum Data Rate: Up to 10 kbps (Receiver), 20 kbps (Transmitter)

• Transmission Range: Up to 200 m (open area)

• Antenna Support: External 433MHz antenna

• Operating Temperature: -40°C to +85°C

• Package Contents: 1 × RF Transmitter Module, 1 × RF Receiver Module, 2 × Antennas

Applications

• Wireless remote control systems.

• Arduino and Raspberry Pi projects.

• Home automation and IoT devices.

• Wireless sensor networks.

• Security and alarm systems.

• Robotics and automation projects.

• Wireless data communication between microcontrollers.
